In Stock Machines
2023 Hexram MT-2510
Specifications:
| Controller (FANUC) | 30i-Model B |
| Control Interface (FANUC) | iHMI PRO 19-inch Touch-Scree |
| Table Size (coverage exceeds table size) (x 2) | 60 in (Y) x 120 in (X) |
| Travel (minimum) / X-Axis | 197 in |
| Travel (minimum) / Y-Axis | 159 in |
| Travel (minimum) / Z-Axis | 52 in |
| Maximum Speed / Machining / X-Y | 800 in / min |
| Maximum Speed / Machining / Z | 600 in / min |
| Maximum Speed / Rapid / X-Y | 1,600 in / min |
| Linear Encoders on X, Y, and Z | Absolute, enclosed, pressurized 5um |
| Position Accuracy (each axis) per 40in (1 m) * | 0.0006 in |
| Position Repeatability (each axis) per 40in (1 m) * | 0.0004 in |
| Spindle Speed | Spindle Type Liquid-Cooled, Electric, Synchronous |
| Spindle Type | Liquid-Cooled, Electric, Synchronous |
| Tooling Type | HSK A63 |
| ATC Tool Chain Positions (w/ load-unload arm) (x 2) | 2 x 40 tools |
| Machine Power | 460 / 3PH (FLA = 350) |
| Air Requirements | 35 CFM (Clean to 20um / and Dry) |
| Chip Conveyors with Coolant Management | 3 x Flat Scraper Type and 1 x Goose Neck Scraper Type |
| Chiller | Included |
| Auto-Lubrication System (Grease) | Included, electric |
| Hydraulic System (for brakes, drawbar, ATC) | Included |
- MT-2510 High Productivity 5-Axis Bridge Type Machining Center
- Machine can be operated as a pallet change machine or as a single table machine tool with both tables operating in tandem with each other covering the following axis travels: X:5000 (197”) and Y:4050 (160”)
- 2 x RMP 60 Renishaw probes are included.
- ZPS zero-point hydraulic clamping for fixtures and/or pallets are included.
- The 72” x 156” T-slotted pallets shown are an option
Huron 2021 Model NX-70 with siemens 828 control
Specifications:
| X-axis: | 4200mm |
| Y-axis: | 2760mm (bridge-cross) |
| Z-axis: | 800mm (Vertical-ram) |
| Table size: | 3500x2000mm, 10,000kg load capacity |
| Scale: | Linear glass scale for all 3-axis |
| Coolant thru spindle: | 20 Bar/30 lpm |
| Job probe system: | Renishaw RMP-60 |
| Rotary table: | 630mm dia. (UCAM-URH 631) |
| Automatic tool changer: | 24-Tools |
| Additional Spec: | Leveling pad |
| Additional Spec: | Machine tower light |
| Additional Spec: | Chip conveyor |
| Additional Spec: | Ethernet |
| Additional Spec: | Spindle head cooling system |
| Additional Spec: | Half guarding |
| Additional Spec: | MPG unit |
| Additional Spec: | Air gun for cleaning |
| Additional Spec: | Hydro-pneumatic booster for hydraulic clamping |
| Extra Resource: | Machine manual hard copy |
Delivery: Service package – machine installation, 4 days operator training and 1 year warranty
Terms: Price, FOB Cincinnati, OH
Comments: Two of these machines are available
Price: Call for price
Mausa FVM 71
Specifications:
| X-axis travel: | 78.7 (2000) |
| Y-axis travel: | 63 (1600) |
| W-axis travel: | 27.6 (700) |
| Z-axis travel: | 63 (1600) |
| Rapid X,Y,Z: | 1181 ipm (30,000 mm/min.) |
| Rapid W: | 787 ipm (20,000 mm/min.) |
| Table size: | 63” x 70” (1600x1800) |
| Table load capacity: | 22,000 lbs. (10,000kg. |
| Hydrostatic rotary table: | .001 degree contouring |
| Spindle diameter: | 5.1” (130mm) |
| Spindle taper: | ISO 50 |
| Spindle power: | 50/61 HP |
| Spindle torque S1/S6: | 16,324/19,91 lb./in. (1844/2250 Nm) |
| Spindle RPM: | 1-4000 |
| Gear ranges: | 2 |
| Control: | Heidenhain iTNC 640 control |
| Chip conveyors: | (2) internal auger, (1) hinged belt |
| Additional Spec: | 60-position ATC |
| Additional Spec: | RMP 60 spindle probe |
Delivery: Service package – machine installation, 4 days operator training and 1 year warranty
Terms: Price, FOB Cincinnati, OH
Comments:
Price: Call for price
Heavy Duty CNC Lathe Romi C 1800Hx 8500 mm
Specifications:
| Swing over carriage: | 1200 mm |
| Control: | Siemens 840D sl |
| Swing over bed: | 1800 mm |
| Turning length: | 8500 mm |
| Maximum workpiece weight: | 30,000 kg |
| Boring support: | up to 250 mm bar |
| Speed range in X & Z: | 8 m/min |
| Spindle bore diameter: | 305mm |
| Spindle speed 2-ranges: | 1/500 |
| Spindle nose: | A2-2- |
| Main spindle motor S1/S6: | 82 kW/ 114 kW |
| Tailstock quill diameter: | 290 mm |
| Tailstock quill travel: | 300 mm |
| Chuck diameter: | 1200 mm, 4 jaw |
| Coolant system: | external and thru tool |
| Additional Spec: | 8 position tool disk turret |
| Additional Spec: | Chip conveyor |
| Turning tool holders: | 4 units |
| Boring bar holder: | 4 units |
| Autotransformer: | 220 to 440AVC |
| Shop electric: | 480 volt, 3 phase |
| Color: | standard Romi colors |
Delivery: Service package – machine installation, 4 days operator training and 1 year warranty
Terms: Price, FOB Cincinnati, OH
Comments:
Price: Call for price
